Color Rendering Index - a measure of the ability of a light source to reveal the colours of objects compared to a natural source.
The highest value is 100.
>90 good LED.
>80 standard LED.
<24 sodium light sources.
The ability of the light source not to generate any flicker in cameras.
Wavelength changing when dimming the light source. In halogen, it's from 1600K on lower values (warm colour) to 2900K on high values (colder).
Halogen is characterized by very smooth dimming. The heating-up tungsten reacts with a slight delay, making the dimming extremely smooth and pleasing to the eye.
Halogen 230W is a very strong light source (5000lm). Can be used as a strong blinder.
| Dimensions | 172 x 21 x 17 cm (67.7 x 8.3 x 6.7 in) |
|---|---|
| Weight | 12,5 kg (27,5 lbs) |
| Rigging |
- base (included) - 2 x 12 mm (1/2 in) holes for clamp on back - hanging adaptor (included) with 12 mm (1/2 in) hole for clamp on top |
| Mounting position | Any |
| Input voltage | 230V 50Hz/60Hz |
| Power consumption | max 1 380W |
| Power connector | Neutrik PowerCon TRUE1 |
| Control connector | Neutrik 3 & 5 PIN XLR (both: in & out) |
| Light sources |
6 x halogen R7s 118mm OSRAM Haloline PRO 230V 230 W (high efficiency) |
| Color temperature | 1 600 - 2 900K |
| CRI | 100 |
| Optics | High reflective hammered reflector |
| Control features |
- 6 DMX channels - RDM - W-DMX (additional option, can be upgraded any time later) |
| User interface |
- High-contrast LCD display - Highlighted buttons |
| Other details |
- silver reflector (standard, can be swapped) - gold reflector (additional option, can be swapped) - flight cases (4-row) (additional option) |
| Warranty | 24 months |
| IP rating | IP20 |
| What's in the box | - Fixture - 2m power cord (PowerCon <-> no plug, naked ends) - user manual - 1x spare lamp - base - height adaptor - hanging adaptor - 3x spigots & cotters |
| Libraries: | GrandMA2, ChamSys, ADJ MyDMX, Avolites Titan, Wysiwyg, Vectorworks, Capture, Realizzer... (download here) |
All designs registered and protected by law.Don't risk - buy originals!
